Basic functions of the product
Liquid transportation: It can transport a variety of media such as clean water and slightly corrosive liquids. It has a wide flow range and can meet the needs of transferring liquids from one place to another in different scenarios. Pressure boost: The centrifugal force generated by the high-speed rotation of the impeller increases the liquid pressure, allowing the liquid to overcome the pipe resistance and achieve long-distance or high-drop transportation. Stable operation: The compact structure and vertical design save space. The stainless steel material is corrosion-resistant and durable. It runs smoothly and has low noise, and can work continuously for a long time.
Usage Environment
Temperature range: Suitable for working environment of -20℃ to 120℃. Medium properties: Can transport clean water and slightly corrosive liquids. However, the volume ratio of solid particles in the medium should be ≤0.1%, and the particle size should be ≤0.2mm. Installation environment: It should be installed in a dry and well-ventilated place, avoid direct sunlight and rain, and the installation foundation should be firm and flat.
Product Advantages
H Stainless Steel Centrifugal Pump - 316L SS Construction, 100m³/h Flow, ANSI/ISO Standard
Excellent material: Made of stainless steel, it is highly corrosion-resistant, can transport a variety of corrosive liquids, and has a long service life. Reasonable structure: The vertical structure is compact, occupies a small area, is easy to install and maintain, and can flexibly adapt to different space layouts. Excellent performance: Smooth operation, low noise, wide range of flow and head, can meet the needs of various working conditions, and has high work efficiency.
Technical Parameters
| Pump Type | IH stainless steel centrifugal pump |
| Material | 304/316 |
| Drive type | electric |
| Maximum flow | 400 cubic meters |
| Maximum lift | 125m |
| Installation Type | Horizontal |
| Maximum caliber | DN200 |
| Maximum Power | 110KW |
| Protection level | IP54 |
| Insulation class | F |
| Standard voltage | AC 220V, 230V, 240V, 380V, 400V, 415V, 440V |
Product Usage
Industrial field: transporting corrosive raw materials and finished products in chemical production; used for material transportation and cleaning operations in the food and beverage industry; involved in liquid medicine transportation and circulation in pharmaceutical companies. Civilian scene: used in the water supply system of high-rise buildings to ensure stable water supply for residents; can also be used for water supply and drainage in communities, schools and other places to maintain normal operation of water circulation.
Product Operation Guid
1. Installation Choose a dry and ventilated place with a solid foundation, place the pump body horizontally, fix it with anchor bolts, connect the inlet and outlet pipes and install the filter.
2. Before starting Check the connection parts, fill with water and exhaust, confirm the direction of the motor, and close the outlet valve.
3. Start Power on and start. After the motor is normal, slowly open the outlet valve to adjust the flow and head, and pay attention to the operating conditions.
4. Operation adjustment Adjust the outlet valve opening to control the flow and head, or use a regulating valve or inverter for precise adjustment.
5. Maintenance Check the seal regularly, clean the filter, change the lubricating oil, and stop the machine to drain the fluid to prevent rust.
Frequently asked questions
Insufficient flow: The reasons are blockage of the pump body or pipeline, the valve is not fully open, the air intake is not tight, and the speed is low. The solution is to clean up the debris, fully open the valve, repair the seal, and adjust the speed. Insufficient lift: It may be that the actual lift exceeds the design, the impeller is worn, and there is air in the pump. The countermeasures are to replace the pump, replace the impeller, and re-vent. Abnormal vibration and noise: due to the eccentricity of the pump shaft and motor shaft, loose anchor bolts, foreign matter in the pump, and bearing problems. The solution is to calibrate the concentricity, tighten the bolts, clean up foreign matter, and handle the bearings. Pump body leakage: caused by damaged seals, cracks in the pump body pipeline, and improper installation. It can be solved by replacing seals, repairing cracks, and reinstalling. Motor overload: caused by excessive flow, foreign matter in the pump, and motor failure. It is necessary to reduce the flow, clean up foreign matter, and repair the motor.
